Walk-In Hood

Walk-In Fume Hood

Large apparatus or complex set-ups may require the use of a Fume Hood specifically designed to meet these requirements. The Walk-In Fume Hood has two vertical rising sashes that allow you to roll in large equipment or portable work stations.

Design

  • Two independently operating full view vertical rising sashes.
  • Sash is 7/32" laminated safety glass with full width flush PVC pull.
  • Includes audible LOC500 airflow monitor for safety.
  • Counterweight provides one finger operation.
  • Hood entrance is framed with inward-angled members to minimize turbulence and provide smooth air movement in hood at face velocities ranging from 60 to 150 FPM.
  • Standard "Resin-Chem" Liner with removable access panels.
  • Removable exterior side panels.
  • Double wall construction for ease of routing service piping.
  • Removable exterior side panels.
  • Lights are mounted above a sealed safety glass panel keeping corrosive fumes and hazardous vapors isolated.
  • Tube lights can easily be replaced through the top front.

Options

  • A variety of optional service fixtures are available from LOC for installation in the Walk-In Fume Hood.
  • Mounting holes for service fixtures and electrical receptacles are pre-cut and capped when fixtures are not required.

Specifications

Walk-In Fume Hood DimensionsWalk-In Fume Hood Specs

The static pressures listed above are for the hoods only. An appropriate amount will need to be added to this figure to compensate for the pressure drop through the duct system. The total pressure drop through the hood and the duct system must be known to select the proper exhaust blower.
